SDM-4000L
  • Intel® Smart Display Module with Intel® Celeron® N4000 Processor, Fanless Design
spec
Ordering Information
9MZGLKALMR-SI (Box packing)
Key Features
  • Intel® Celeron® N4000 Processor
  • Dual Channel DDR4, 2 x SO-DIMMs
  • 1 x GbE LAN Port
  • HDMI and DP for dual display outputs
  • M.2 with SATA III 6Gb/s
  • 4 x USB 3.2 Gen 1
  • 1 x eMMC 32GB
Application
  • Digital Signage
  • Menu Board
  • Video Wall
  • Interactive Whiteboard

    As display panels become thinner and power-effecient with high performance, Intel® is presenting Smart Display Module (SDM), it's almost one-third size of OPS, but still an all-in-one integrated board with full computing capability powered by Intel® Celeron® N4000 processor and Intel® UHD Graphics 600 chipset - support dual independent display output of 1 x HDMI and 1 x Display Port up to 4K resolution as well as 4 x USB 3.2 Gen 1 for various peripheral connections.

    Its form factor without enclosure brings the benefit of cost-effective on total solution design and integration flexibility to meet space-limited requirement.  It can be built in or externally plugged into a display panel to work mainly for commercial and retail markets, such as Interactive Whiteboard, menuboard, video wall, KIOSK and digital signage, etc.   The end user can update software content from remote location, and furthermore, quickly remove and replace SDM for maintainance or hardware upgrade purpose to save CAPEX and OPEX.




Specification


Form Factor

SDM-Large

175W x 100D(mm)

CPU

Intel® Celeron® N4000 Processor

14nm, 2 cores, 2 threads, up to 2.6 GHz

TDP 6W

Socket

1 x FCBGA 1090

Memory

2 x DDR4 SO-DIMM sockets, Max. Capacity 8 GB

Support Dual channel DDR4 2400 MHz memory modules

Ethernet

1 x GbE LAN Port (Realtek® RTL8111HS)

Video

Integrated Graphics Processor - Intel® UHD Graphics 600:

1 x HDMI 2.0 port (SDM), supporting a maximum resolution of 4096x2160 @60Hz

1 x DP port (Rear/SDM side), supporting a maximum resolution of 4096x2160 @60Hz


(2 independent display outputs)

Audio

Intel® Integrated Audio

Storage

1 x eMMC 32GB

Expansion Slots

1 x 2280 M.2 M-Key (SATA 6Gb/s)

1 x 2230 M.2 E-key (WiFi/BT)

Rear I/O

1 x Display Port

1 x RJ45 LAN Port

4 x USB 3.2 Gen 1

1 x PWR LED

1 x HDD LED

2 x External Antenna Holes (Optional)

1 x Reset button

1 x Power button

OS Compatibility

Windows 10 (x64)

Operating Properties

Operating temperature: 0°C to +55°C

Operating humidity: 0-90% (non-condensing)

Non-operating temperature: -40°C to +85°C

Non-operating humidity: 0%-95% (non-condensing)

Packing ContentCarton size: 465 x 351 x 217 (mm)
Packing Capacity: 10pcs

Single Box size: 221 x 178 x 65 (mm)
Single Box weight: Approx. 0.46kg

Including:
Screw Kit with #0 ZIPLOCK BAG SCREW-BIND M3.0*L5.0 NI x 2pcs (P/N: 25KSD-130053-S0R)
Order Information

9MZGLKALMR-SI (Box packing)
