GIGAIPC QBiP-7100AT
  • 3.5” SubCompact Wide Temperature Board with 7th Generation Intel® Core™ i3-7100U Processor
  • Dual Channel DDR4 memory, 4 x COM , 2 x SATA 6Gb/s, 6 x USB, Temp -20°C to 70°C



Key Features
  • 3.5’’ SBC
  • Intel® Core™ i3-7100U Processor
  • Dual Channel DDR4, 2 x SO-DIMMs
  • Intel® Optane™ Memory Ready
  • 2 x GbE LAN Ports
  • 2 x SATA 6Gb/s Ports
  • Ultra-Fast M.2 with PCIe Gen3 x4 interface
  • HDMI2.0, Display Port, LVDS ports for multiple display
  • 1 x COM Port (RS-232/422/485 & RI/5V/12V)
  • 3 x COM Ports (RS-232)
  • Wide Temperature Embedded Motherboard







​





​





QBiP Wide Temperature Series are 3.5" SubCompact Boards designed for applications in harsh environment or extreme temperature conditions.  It supports two temperature ranges : -20°C to 70°C and -40°C to 85°C, with fan-less thermal solutioin, for different level of performance in various operating environments.
QBiP-7100AT is equipped with 7th Generation Intel® i3-7100U Processor, 15W TDPs, dual channel DDR4-2133 MHz memory up to 32G and rich I/O interfaces of 4 x COM Ports (1 x switchable and 3 x RS-232), 1 x GPIO (8 bits) and 6 x USB etc, for flexible functionality to fulfill versatile industrial requirements.  Furthermore, it provides great expansion with 2280 M.2 M-key slot to support high speed PICex4 SSD / M.2 SSD and SIM slot for cellular connection.

​

​

​

​

​

Specification​

​

Form Factor

3.5" SBC

146W x 101.7D(mm)

CPU

Intel® Core™ i3-7100U Processor

14nm, 2 cores, 4 threads, 2.4 GHz

TDP 15W

3 MB SmartCache

Socket

1 x FCBGA 1356

Memory

2 x DDR4 SO-DIMM sockets, Max. Capacity 32 GB

Support Dual channel DDR4 2133 MHz memory modules

Ethernet

2 x GbE LAN Ports

(Intel® I219V and Intel® I211AT)

Video

Integrated Graphics Processor - Intel® HD Graphics 620:

1 x HDMI 2.0 port, supporting a maximum resolution of 4096x2160 @60Hz

1 x DP port, supporting a maximum resolution of 4096x2160 @60Hz

1 x LVDS port, supporting a maximum resolution of 1920x1080 @60Hz


(3 independent display outputs)

Audio

Realtek® Audio Codec

Storage

2 x SATA 6Gb/s Ports (RAID 0/1/5)

Expansion Slots

1 x 2280 M.2 M-Key (PCIe x4, SATA 6Gb/s)

1 x 2230 M.2 E-Key (WiFi/BT)

1 x Full-size Mini PCIe with SIM slot (PCIe x1 + USB2.0) -- support 3G/4G module

Internal I/O

1 x 4-pin box power connector (+9V~36VDC)

2 x SATA Power headers

1 x CPU fan header

1 x System fan header

1 x Front panel header

1 x Front panel audio header

1 x 2W Speaker out header

2 x USB 2.0 headers

3 x COM headers (RS-232)

1 x Backlight Control header

1 x AT/ATX mode select jumper

1 x GPIO (8-bits) & SMBUS header

Rear I/O

1 x COM Port (RS-232/422/485 & RI/5V/12V)

1 x HDMI

1 x Display Port

2 x RJ45 LAN Ports

4 x USB 3.2 Gen 1

TPM

1 x TPM header

OS Compatibility

Windows 10 (x64)

Operating Properties

Operating temperature: -20°C to 70°C

Operating humidity: 0-90% (non-condensing)

Non-operating temperature: -20°C to 70°C

Non-operating humidity: 0%-95% (non-condensing)

Packing ContentCarton size: 375 x 324 x 293 (mm)
Packing Capacity: 10pcs

Single Box size: 256 x 175 x 59 (mm)

Including:
SATA power Cable x 1 (P/N: 25CRI-200B02-K1R)
Fanless Heatsink x 1 (P/N: 25ST1-153108-A7R)
Order Information

9MFLP3ASMR-SI1 (Box Packing)

Optional Kit

TPM 2.0 module P/N: 9CTM000NR-00

TPM Cable P/N: 25CRZ-100600-S9R
